AI Model Zoo Architecture¶

Overview¶

The AI model zoo provides comprehensive visual analysis for home security through multiple specialized models working together.

Two inference runtimes exist in this repo, and only one runs in production:

1. ai-gateway — the deployment topology in docker-compose.prod.yml. One container (port 8090) fronts NVIDIA Triton with a FastAPI translation layer and serves YOLO26, Florence-2, CLIP and both enrichment tiers under router prefixes. See ai/gateway/AGENTS.md.
2. Legacy per-model containers — ai-florence, ai-clip, ai-enrichment and ai-enrichment-light. Each loads its models on demand under a VRAM budget with LRU eviction. The ai-florence, ai-clip and ai-enrichment images are still built by .github/workflows/deploy.yml (only ai-enrichment-light survives as a source directory, with no deploy.yml matrix entry), but none of these are services in docker-compose.prod.yml. ai-yolo26 was in this list until its image was retired fully on 2026-09-23 — recipe at archive/ai-yolo26-image/Dockerfile.

The sections below give the production router path for each model first, and note the legacy container's port and response shape where the two differ. The on-demand loading machinery in VRAM Management applies only to the legacy containers and to the backend's own model zoo.

Architecture Diagram¶

Current production topology:

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#3B82F6',
    'primaryTextColor': '#FFFFFF',
    'primaryBorderColor': '#60A5FA',
    'secondaryColor': '#A855F7',
    'tertiaryColor': '#009688',
    'background': '#121212',
    'mainBkg': '#1a1a2e',
    'lineColor': '#666666'
  }
}}%%
flowchart TB
    subgraph Pipeline["Detection Pipeline"]
        CAM[Camera Frame] --> YOLO[YOLO26]
        YOLO --> DET[Detections]
        DET --> ENR[Enrichment]
        ENR --> NEM[Nemotron]
    end

    subgraph GW["ai-gateway :8090 (FastAPI) -> Triton :8001 gRPC, GPU"]
        YR["/yolo26"]
        FR["/florence"]
        CR["/clip"]
        HR["/enrichment<br/>vehicle, fashion, demographics, action"]
        LR["/enrich-lt<br/>pose, threat, reid, pet, depth"]
    end

    subgraph LLM["ai-llm :8091"]
        NEMC[Nemotron-3-Nano-30B llama.cpp]
    end

    Pipeline --> GW
    Pipeline --> LLM

Service Architecture¶

Services In Production (docker-compose.prod.yml)¶

Port variables come from .env: AI_GATEWAY_PORT, AI_GATEWAY_METRICS_PORT and LLM_PORT.

How The Backend Reaches Each Model¶

USE_AI_GATEWAY=true in .env.example and in the compose backend environment selects the gateway. The base URLs in .env.example carry the router prefix:

Legacy Enrichment Split¶

The legacy containers still split enrichment models across two services by GPU requirement, and ENRICHMENT_<TASK>_SERVICE in .env still routes between heavy and light:

The same variable names control the gateway, where "heavy" and "light" select the /enrichment and /enrich-lt routers rather than separate GPUs. See AI Enrichment Light Service for the legacy service documentation.

Enrichment Pipeline Split¶

The backend routes each detection to either the heavy or the light target. In the legacy deployment those land on two different GPUs with different VRAM budgets; in the gateway deployment they are two routers over one Triton instance.

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#3B82F6',
    'primaryTextColor': '#FFFFFF',
    'primaryBorderColor': '#60A5FA',
    'secondaryColor': '#A855F7',
    'tertiaryColor': '#009688',
    'background': '#121212',
    'mainBkg': '#1a1a2e',
    'lineColor': '#666666'
  }
}}%%
flowchart TB
    DET[Detection from YOLO26] --> ROUTER{Enrichment Router}
    ROUTER -->|Heavy models| HEAVY["/enrichment"]
    ROUTER -->|Light models| LIGHT["/enrich-lt"]
    subgraph HEAVY_SVC["Heavy targets"]
        FC[FashionSigLIP]
        VC[Vehicle Classifier]
        DM[Demographics]
        XC[Action Recognition]
    end
    subgraph LIGHT_SVC["Light targets"]
        PR[Person Re-ID]
        PE[Pose Estimation]
        TD[Threat Detection]
    end
    HEAVY --> HEAVY_SVC
    LIGHT --> LIGHT_SVC

Data Flow¶

%%{init: {
  'theme': 'dark',
  'themeVariables': {
    'primaryColor': '#3B82F6',
    'primaryTextColor': '#FFFFFF',
    'primaryBorderColor': '#60A5FA',
    'secondaryColor': '#A855F7',
    'tertiaryColor': '#009688',
    'background': '#121212',
    'mainBkg': '#1a1a2e',
    'lineColor': '#666666'
  }
}}%%
flowchart TB
    CAM[Camera Images]
    CAM --> YOLO["YOLO26<br/>ai-gateway :8090/yolo26"]
    YOLO --> ENR["Enrichment<br/>ai-gateway :8090/enrichment"]
    YOLO -->|Detections| NEM
    ENR -->|Classified Detections| NEM
    NEM["Nemotron :8091<br/>Risk Analysis & Scoring"]
    NEM --> EVT[Risk Events]

Model Details¶

Always-Loaded Models¶

YOLO26 (gateway router /yolo26)¶

In production the gateway serves this model at http://localhost:8090/yolo26 (Triton name yolo26). The legacy standalone container answered on port 8095.

• Model: YOLO26m (Ultralytics with TensorRT)
• Architecture: YOLO26 object detection with TensorRT FP16 optimization
• VRAM: ~2GB (with TensorRT FP16 engine)
• Inference Time: 10-20ms (FP16 TensorRT)
• Output: Bounding boxes with class labels and confidence scores

Security Classes (Filtered):

SECURITY_CLASSES = {"person", "car", "truck", "dog", "cat", "bird", "bicycle", "motorcycle", "bus"}

API Endpoints (under the /yolo26 router):

• GET /yolo26/health - Health status
• POST /yolo26/detect - Single image detection
• POST /yolo26/detect/batch - Batch detection

Florence-2 (gateway router /florence)¶

In production the gateway serves florence-2-base (microsoft/Florence-2-base in models.yml, Triton name florence2) at http://localhost:8090/florence. The legacy standalone container loaded Florence-2-large and answered on port 8092.

• Architecture: Vision-language transformer
• VRAM: ~1GB download (size_mb: 1024 in models.yml)
• Inference Time: 100-300ms per query
• Tasks: Caption, Dense Region Caption, OCR, Open Vocabulary Detection

Supported Prompts:

API Endpoints (under the /florence router, ai/gateway/adapters/florence.py):

• GET /florence/health - Health status
• POST /florence/extract - Generic extraction with prompt
• POST /florence/batch-extract - Multiple prompts in one call
• POST /florence/ocr - Text extraction
• POST /florence/ocr-with-regions - Text with bounding boxes
• POST /florence/detect - Object detection
• POST /florence/dense-caption - Region captioning
• POST /florence/describe-region - Caption one region
• POST /florence/phrase-grounding - Ground a phrase to boxes
• POST /florence/detect_security_objects - Pre-formatted security prompt

CLIP (gateway router /clip)¶

In production the gateway serves SigLIP 2 Base (onnx-community/siglip2-base-patch16-224-ONNX, registered in models.yml under the Triton names clip and clip_text) at http://localhost:8090/clip. The legacy standalone container loaded openai/clip-vit-large-patch14 and answered on port 8093.

• Architecture: Vision-Language contrastive model (ONNX)
• VRAM: 200MB (vram_mb in models.yml)
• Embedding Dimension: 768
• Output: Normalized image embeddings, similarity scores

The clip_text half runs on CPU: it is a quantized INT8 model whose MatMulInteger ops block the CUDA execution provider (comment in models.yml).

Use Cases:

• Scene anomaly detection via baseline comparison
• Zero-shot classification

Person re-identification moved off this router with the full swap (ledger item 20): the person-vector space is OSNet-AIN x1.0 (osnet-ain-x1-0, 512-dim) in the backend.

API Endpoints (under the /clip router, ai/gateway/adapters/clip.py):

• GET /clip/health - Health status
• POST /clip/embed - Generate 768-dim embedding
• POST /clip/anomaly-score - Compare to baseline
• POST /clip/classify - Zero-shot classification
• POST /clip/similarity - Image-text similarity
• POST /clip/batch-similarity - Batch similarity comparison

Nemotron (ai-llm:8091)¶

Production Model:

• Model: nvidia/Nemotron-3-Nano-30B-A3B-GGUF (Q4_K_M quantization)
• Architecture: Large Language Model via llama.cpp with Mixture-of-Experts (MoE) routing
• Parameters: 30 billion (A3B active routing variant)
• VRAM: ~14.7GB
• Context Window: CTX_SIZE=262144 in .env.example (llama.cpp splits it across PARALLEL=8 slots of 32,768 tokens each)
• GPU Layers: GPU_LAYERS=auto — llama.cpp --fit decides based on free VRAM
• Purpose: Risk reasoning, threat analysis, natural language generation

Development Model (resource-constrained environments):

• Model: bartowski/nemotron-mini-4b-instruct-GGUF (Q4_K_M quantization)
• Parameters: 4 billion
• VRAM: ~3GB
• Context Window: 4,096 tokens

Risk Score Ranges:

On-Demand Models (Enrichment Services)¶

Every model in this section is registered in models.yml with priority: medium except smoke-fire-yolov8n, which is priority: critical with preload and never-evict set. In the gateway deployment Triton loads the enrichment models at container start, so the headings below describe which router answers each request, not a load-on-demand order. Under the legacy containers the manager evicted models by LRU within a budget — see VRAM Management.

The legacy containers split the models across two services:

• ai-enrichment (port 8094): Heavy transformer models running on GPU 0 (~6.8GB budget, VRAM_BUDGET_GB default in ai/enrichment/model.py)
• ai-enrichment-light (port 8096): Small efficient models running on GPU 1

In production the same split survives as two routers on one gateway: /enrichment and /enrich-lt. The backend still picks between them with the ENRICHMENT_*_SERVICE environment variables (e.g. ENRICHMENT_POSE_SERVICE=light in docker-compose.prod.yml).

Threat Detection¶

• Model: Subh775/Threat-Detection-YOLOv8n (triton_name: threat)
• VRAM: 300MB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrich-lt/threat-detect
• Purpose: Detect weapons (knives, guns, bats — classes per the models.yml description)
• Trigger: Person detections in security-sensitive contexts

Input: Cropped person image. Output (ThreatResponse in ai/gateway/adapters/enrichment_light.py):

{
  "threats_detected": [{ "class": "knife", "confidence": 0.89, "bbox": [...] }],
  "is_threat": true,
  "max_confidence": 0.89,
  "inference_time_ms": 12.4
}

The legacy container returned a different shape (detected, threat_type, severity per threat — ThreatDetectionResult in ai/enrichment/models/threat_detector.py).

Pose Estimation¶

• Model: YOLOv8n-pose (triton_name: pose, 200MB in models.yml). vitpose-small also ships in models.yml (1.5GB, backend service); ai/enrichment/vitpose.py is the legacy container's analyzer.
• Served at: POST http://localhost:8090/enrich-lt/pose-analyze (a second POST /enrichment/pose-analyze exists on the heavy router)
• Purpose: Body pose detection, posture classification
• Trigger: Person detections
• Output: 17 COCO keypoints per person (num_people beside them)

COCO Keypoints:

COCO_KEYPOINT_NAMES = [
    "nose",
    "left_eye",
    "right_eye",
    "left_ear",
    "right_ear",
    "left_shoulder",
    "right_shoulder",
    "left_elbow",
    "right_elbow",
    "left_wrist",
    "right_wrist",
    "left_hip",
    "right_hip",
    "left_knee",
    "right_knee",
    "left_ankle",
    "right_ankle",
]

Posture Classifications (_derive_posture in ai/gateway/adapters/enrichment_light.py): standing, crouching, lying, bending, unknown

Security Alerts the gateway emits from a posture:

• crouching - "Person is crouching - potentially hiding or concealing activity"
• lying - "Person is lying down - possible medical emergency or unusual behavior"

The legacy container classified more postures (running, reaching_up and others — ai/enrichment/models/pose_estimator.py).

Demographics¶

• Models: nateraw/vit-age-classifier + rizvandwiki/gender-classification (Triton names demographics_age and demographics_gender, 200MB each in models.yml)
• Served at: POST http://localhost:8090/enrichment/demographics
• Purpose: Age range and gender estimation from face crops
• Trigger: Person detections with visible face

Input: Cropped face image. Output:

{
  "age_range": "21-30",
  "age_confidence": 0.82,
  "gender": "male",
  "gender_confidence": 0.94,
  "inference_time_ms": 22.1
}

The gateway maps model class indices onto 0-10, 11-20, 21-30, 31-40, 41-50, 51-60, 61-70, 71+ (ai/gateway/adapters/enrichment.py). The legacy AGE_RANGES list in ai/enrichment/models/demographics.py is a different vocabulary (21-35, 36-50, 51-65, 65+ among them).

Clothing Analysis¶

• Model: Marqo/marqo-fashionSigLIP (FashionSigLIP) - models.yml describes the upgrade from FashionCLIP as +57%
• VRAM: 500MB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrichment/clothing-classify
• Purpose: Identify clothing types, uniforms, suspicious attire
• Trigger: Person detections

Security-Focused Prompts:

SECURITY_CLOTHING_PROMPTS = [
    "person wearing dark hoodie",
    "person wearing face mask",
    "person wearing ski mask or balaclava",
    "delivery uniform",
    "Amazon delivery vest",
    "FedEx uniform",
    "UPS uniform",
    "USPS postal worker uniform",
    "casual clothing",
    "business attire or suit",
    ...,
]

Output:

{
  "clothing_type": "hoodie",
  "color": "dark",
  "style": "suspicious",
  "confidence": 0.85,
  "is_suspicious": true,
  "is_service_uniform": false
}

Vehicle Classification¶

• Model: AventIQ-AI/ResNet-50-Vehicle-Segment-classification (models.yml; Triton name vehicle) — ResNet-50 over the MIO-TCD segments
• VRAM: 1.5GB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrichment/vehicle-classify
• Purpose: Vehicle type identification
• Trigger: Vehicle detections (car, truck, bus, motorcycle, bicycle)

Vehicle Classes:

VEHICLE_SEGMENT_CLASSES = [
    "articulated_truck",
    "background",
    "bicycle",
    "bus",
    "car",
    "motorcycle",
    "non_motorized_vehicle",
    "pedestrian",
    "pickup_truck",
    "single_unit_truck",
    "work_van",
]

Output:

{
  "vehicle_type": "pickup_truck",
  "display_name": "pickup truck",
  "confidence": 0.92,
  "is_commercial": false
}

Pet Classification¶

• Model: microsoft/resnet-18 (triton_name: pet)
• VRAM: 200MB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrichment/pet-classify (also POST /enrich-lt/pet-classify)
• Purpose: Dog/cat classification for false positive reduction (breed is a passthrough field the classifier does not infer)
• Trigger: Animal detections (dog, cat)

Output:

{
  "pet_type": "dog",
  "breed": "unknown",
  "confidence": 0.98,
  "is_household_pet": true
}

Person Re-ID¶

• Model: OSNet-AIN x1.0 (osnet-ain-x1-0 in models.yml, Triton name reid)
• VRAM: 100MB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrich-lt/person-reid
• Purpose: Generate 512-dimensional embeddings for tracking individuals
• Trigger: Person detections requiring cross-camera tracking

Output:

{
  "embedding": [0.123, -0.456, ...],  // 512 floats
  "embedding_dimension": 512
}

Vehicle Damage Detection¶

• Model: harpreetsahota/car-dd-segmentation-yolov11 (YOLOv11x-seg)
• VRAM: 2GB (vram_mb in models.yml)
• Where it runs: the backend model zoo — service: backend in models.yml, so the gateway does not serve it
• Purpose: Detect and segment vehicle damage for security analysis
• Trigger: Vehicle detections (car, truck, bus, motorcycle)
• License: AGPL-3.0

Damage Classes:

DAMAGE_CLASSES = [
    "crack",  # Surface cracks in paint/body
    "dent",  # Impact dents on body panels
    "glass_shatter",  # Broken/shattered glass (HIGH SECURITY)
    "lamp_broken",  # Damaged headlights/taillights (HIGH SECURITY)
    "scratch",  # Surface scratches on paint
    "tire_flat",  # Flat or damaged tires
]

High-Security Damage Types:

Input: Cropped vehicle image from YOLO26 detection

Output:

{
  "detections": [
    {
      "damage_type": "glass_shatter",
      "confidence": 0.87,
      "bbox": {
        "x1": 120.5,
        "y1": 80.2,
        "x2": 180.3,
        "y2": 150.8
      },
      "has_mask": true,
      "mask_area": 2450
    }
  ],
  "damage_types": ["glass_shatter", "dent"],
  "has_high_security_damage": true,
  "total_damage_count": 2,
  "highest_confidence": 0.87
}

Security Alert Pattern Detection:

The model includes pattern analysis for identifying suspicious damage:

# Suspicious patterns that trigger elevated alerts
- glass_shatter + lamp_broken = "break-in pattern"
- Night time (22:00-06:00) + any damage = "elevated risk"
- Multiple damage types (>=2) = "likely incident"
- High-security damage at night = "critical alert"

Context String for LLM:

Vehicle Damage Detected (2 instances):
  - glass_shatter: 1 instance(s) (avg conf: 87%)
  - dent: 1 instance(s) (avg conf: 72%)
  **HIGH SECURITY ALERT**: Suspicious damage types detected

Source Files:

• Loader: backend/services/vehicle_damage_loader.py
• Model Zoo Entry: backend/services/model_zoo.py

Depth Estimation¶

• Model: depth-anything/Depth-Anything-V2-Small-hf, shipped as depth-anything-v2-tiny in models.yml (Triton name depth)
• VRAM: 100MB (vram_mb in models.yml)
• Served at: POST http://localhost:8090/enrich-lt/depth-estimate
• Purpose: Spatial reasoning, distance estimation
• Trigger: Detections requiring distance context

Output (DepthResponse in ai/gateway/adapters/enrichment_light.py):

{
  "depth_map_base64": "<base64-png>",
  "min_depth": 0.8,
  "max_depth": 12.4,
  "mean_depth": 3.5,
  "inference_time_ms": 18.2
}

The legacy container returned estimated_distance_m, relative_depth and proximity_label instead (/object-distance and /depth-estimate in ai/enrichment/model.py).

Action Recognition¶

• Model: stgcn-plus-plus in models.yml — ONNX export of pyskl ST-GCN++ (stgcnpp_ntu60_xsub_hrnet_j.pth, OpenMMLab), served by Triton as stgcn_action (ai/triton/model_repository/stgcn_action/config.pbtxt, ONNX Runtime, KIND_CPU). Skeleton-based: it classifies the 60 NTU RGB+D 60 action classes from COCO 17-joint pose tracks, not from image features. models.yml still carries the superseded xclip-base entry with enabled: false and a "replaced by stgcn-plus-plus" note.
• Footprint: ~14MB ONNX weights (size_mb: 20, vram_mb: 20, triton_kind: KIND_CPU in models.yml — CPU-only, no GPU allocation)
• Served at: POST http://localhost:8090/enrichment/action-classify (the enrichment router, mounted under the /enrichment prefix in ai/gateway/main.py; ALL_MODELS waits for stgcn_action). The backend reaches it via EnrichmentClient.classify_action() (backend/services/enrichment_client.py).
• Purpose: Temporal action classification from a buffered frame sequence
• Trigger: Person detection with action_recognition_enabled and more than one buffered frame (backend/services/enrichment_pipeline.py)

Input: {"frames": ["<base64>", …], "top_k": 5} — a JSON array of base64 frames. _infer_action() (ai/gateway/adapters/enrichment.py) runs each frame through the Triton pose model, keeps the highest-confidence person's 17 COCO keypoints per frame, resamples the track to 100 frames and pads a second person slot with zeros, then feeds the resulting (1, 2, 100, 17, 3) tensor to stgcn_action. The label set is fixed to NTU RGB+D 60 — the endpoint accepts no zero-shot prompts. Frames with no person anywhere in the sequence return action: "unknown" with risk_weight: 0.2 and skip inference.

Output shape (ActionClassifyResponse; all_scores holds the top_k classes, is_suspicious and risk_weight: 0.8 mark the security-relevant classes — falling plus the violence/pickpocketing indices):

{
  "action": "falling",
  "confidence": 0.87,
  "is_suspicious": true,
  "risk_weight": 0.8,
  "all_scores": {
    "falling": 0.87,
    "staggering": 0.08,
    "nod head/bow": 0.03,
    "pickup": 0.02
  },
  "inference_time_ms": 12.4
}

Retired: The X-CLIP Triton model xclip_action has been retired from ai/triton/model_repository/ — its config.pbtxt and model directory now live at archive/triton-model-repository/xclip_action/ pending a provenance ruling. It is absent from ALL_MODELS and from the gateway adapters, so the gateway's serving path is fully on stgcn_action. No live X-CLIP code remains anywhere else either: the enrichment container's action_recognizer was retired to archive/ai-enrichment/ (NEM-5563) and the backend-side xclip_loader.py / action_recognition_service.py chain — including its deprecated pipeline fallback and the /api/action-events analyze endpoint — was archived to archive/xclip-backend-chain/ on 2026-09-23. What's left is configuration provenance only: the xclip-base entry in models.yml (enabled: false, owner-owned) and the independent X-CLIP prompt subsystem (prompt_management/prompt_storage still serve stored X-CLIP class lists, which is a prompt-config surface, not an inference path).

VRAM Management¶

This section describes the on-demand loading machinery in ai/enrichment/model_manager.py (legacy containers) and backend/services/model_zoo.py (backend). The gateway does not run it: Triton loads ALL_MODELS (in ai/gateway/main.py) at container start.

On-Demand Loading Architecture¶

The OnDemandModelManager class manages GPU memory efficiently:

class OnDemandModelManager:
    def __init__(self, vram_budget_gb: float = 6.8):
        self.vram_budget = vram_budget_gb * 1024  # MB
        self.loaded_models = OrderedDict()  # LRU tracking
        self.model_registry = {}

Loading Algorithm¶

1. Request comes in requiring a model
2. If model loaded, use it and update last-used timestamp
3. If not loaded, check VRAM budget
4. If over budget, evict LRU models (respecting priority)
5. Load requested model

Priority System¶

Priorities below are the ones in the legacy registry (ai/enrichment/model_registry.py). The priority field in models.yml (which drives backend model_zoo eviction) is medium for every model except smoke-fire-yolov8n, which is critical.

VRAM Allocation and Eviction Overview¶

The following diagram shows the two-tier VRAM architecture: always-loaded core models consume a fixed budget, while on-demand models share a dynamic budget and are evicted in LRU order respecting priority levels.

flowchart TB
    subgraph Always["Always Loaded (~2.7GB)"]
        Y["YOLO26<br/>~2GB"]
        F["Florence-2-base<br/>~460MB"]
        C["SigLIP 2 Base<br/>~200MB"]
    end
    subgraph Budget["On-Demand Budget (~6GB)"]
        CRIT["CRITICAL<br/>Threat Detection"]
        HIGH["HIGH<br/>Pose, Demographics"]
        MED["MEDIUM<br/>Clothing, Vehicle, Re-ID"]
        LOW["LOW<br/>Depth, Action Recognition"]
    end
    subgraph Eviction["LRU Eviction Order"]
        LOW -.->|Evicted first| FREE[Free VRAM]
        MED -.->|Evicted second| FREE
        HIGH -.->|Evicted when necessary| FREE
        CRIT -.->|Never evicted if possible| FREE
    end

Eviction Strategy¶

Models are sorted by (priority descending, last_used ascending):

• Higher priority numbers (LOW=3) evicted before lower (CRITICAL=0)
• Among same priority, oldest (least recently used) evicted first

candidates = sorted(
    self.loaded_models.items(),
    key=lambda x: (-x[1].priority, x[1].last_used),
)

VRAM Budget Calculation¶

Based on actual values from backend/services/model_zoo.py:

The header of backend/services/model_zoo.py states the backend's own budget: Nemotron LLM 21,700 MB and YOLO26v2 650 MB always loaded, ~1,650 MB left for model-zoo models, loaded sequentially rather than concurrently.

Backend model-zoo VRAM (vram_mb in models.yml):

API Reference¶

Unified Enrichment Endpoint¶

Production (gateway):

POST http://localhost:8090/enrich/enrich

Request (EnrichRequest in ai/gateway/adapters/enrichment.py):

{
  "image": "<base64>",
  "detection_type": "person",
  "bbox": { "x": 0, "y": 0, "width": 100, "height": 100 },
  "extra": {}
}

Response (EnrichmentResponse): a detection_type, an enrichments object whose keys depend on the detection type, and inference_time_ms.

Legacy container (POST http://ai-enrichment:8094/enrich, still built):

Request takes image, detection_type, bbox, frames and an options object (action_recognition, include_depth). Its response has one named field per result (pose, clothing, demographics, threat, reid_embedding, vehicle, pet, action, depth, models_used, inference_time_ms - EnrichmentResponse in ai/enrichment/model.py).

Model Status Endpoint¶

GET http://ai-enrichment:8094/models/status

Legacy container only (SystemStatus in ai/enrichment/model.py). In a gateway deployment the backend exposes model status instead: GET http://localhost:8000/api/system/models and /api/system/models/vram-summary.

Response:

{
  "vram_budget_mb": 6963.2,
  "vram_used_mb": 2300,
  "vram_available_mb": 4663.2,
  "vram_utilization_percent": 33.0,
  "loaded_models": [
    {
      "name": "fashion_clip",
      "vram_mb": 800,
      "priority": "HIGH",
      "last_used": "2024-01-15T10:30:00Z"
    }
  ],
  "registered_models": [
    {
      "name": "vehicle_classifier",
      "vram_mb": 1500,
      "priority": "MEDIUM",
      "loaded": false
    }
  ],
  "pending_loads": []
}

Model Preload Endpoint¶

Legacy container only.

POST http://ai-enrichment:8094/models/preload?model_name=threat_detector

Response:

{
  "success": true,
  "model_name": "threat_detector",
  "vram_mb": 400,
  "load_time_ms": 1250.5
}

Individual Classification Endpoints¶

Gateway routers (base http://localhost:8090, adapters in ai/gateway/adapters/):

The legacy container answers the same names un-prefixed on port 8094, plus /object-distance, /models/unload and /models/registry, which have no gateway equivalent. The gateway has no /models/status or preload route: Triton owns loading there.

Enrichment Result Schema¶

The enrichment pipeline returns structured results for each detection. These results are stored alongside detections and used by Nemotron for comprehensive risk analysis.

EnrichmentResult Structure¶

The backend's EnrichmentResult (backend/services/enrichment_pipeline.py) aggregates per-batch enrichment outputs: license_plates, faces, vision_extraction (Florence-2), person_reid_matches, vehicle_reid_matches, person_household_matches, vehicle_household_matches, scene_change, violence_detection, weather_classification, structured error lists and processing_time_ms. Per-detection model results (pose, demographics, embeddings, ...) are stored on the detection's enrichment_data rather than on this object.

ThreatDetectionResult¶

Weapon and threat detection results from the YOLO threat detector model. These fields come from ThreatDetection.to_dict() in the legacy ai/enrichment/models/threat_detector.py; the gateway's /enrich-lt/threat-detect response instead reports threats_detected, is_threat and max_confidence.

{
  "threat_type": "knife",
  "confidence": 0.89,
  "severity": "high",
  "bbox": [120, 80, 180, 200]
}

AgeClassificationResult¶

Age-group classification from the ViT age classifier, as returned by the backend loader (AgeClassificationResult in backend/services/age_classifier_loader.py). The AI services return a different shape — the gateway reports age_range/age_confidence (see Demographics) and the legacy module a DemographicsResult with age_range/age_confidence.

{
  "age_group": "teenager",
  "confidence": 0.82,
  "display_name": "teenager (13-19 years)",
  "all_scores": { "teenager": 0.82, "child": 0.12, "young_adult": 0.04 },
  "is_minor": true
}

GenderClassificationResult¶

Gender classification from the ViT gender classifier, as returned by the backend loader (GenderClassificationResult in backend/services/gender_classifier_loader.py).

{
  "gender": "male",
  "confidence": 0.94,
  "male_score": 0.94,
  "female_score": 0.06
}

PersonEmbeddingResult¶

512-dimensional embedding vector from OSNet-AIN x1.0 for person re-identification across cameras (PersonEmbeddingResult.to_dict() in backend/services/osnet_loader.py).

{
  "embedding": [0.123, -0.456, 0.789, "..."],
  "detection_id": "det_abc123",
  "confidence": 1.0,
  "embedding_dim": 512
}

Use Cases:

• Cross-camera person tracking
• Person re-identification over time
• Similarity search for matching individuals

Complete Enrichment Response Example¶

Full response from the /enrich endpoint for a person detection:

The legacy container's POST /enrich (port 8094) response for a person detection aggregates its model results directly — the gateway's /enrichment/enrich returns a detection_type / enrichments / inference_time_ms envelope instead (see the API Reference above). Shape, per the named fields of EnrichmentResponse in ai/enrichment/model.py:

{
  "pose": { "keypoints": ["..."], "posture": "standing", "alerts": [] },
  "clothing": { "clothing_type": "casual", "confidence": 0.7 },
  "demographics": { "age_range": "21-30", "gender": "male" },
  "threat": { "has_threat": false, "threats": [] },
  "reid_embedding": [0.123, -0.456, "..."],
  "vehicle": null,
  "pet": null,
  "action": { "action": "walking", "confidence": 0.92 },
  "depth": { "mean_depth": 3.5 },
  "models_used": ["pose_estimator", "threat_detector"],
  "inference_time_ms": 312.5
}

Integration with Risk Analysis¶

Enrichment results feed directly into Nemotron's risk analysis prompt:

1. Threat Detection: Weapons trigger immediate critical risk elevation
2. Demographics: Age/gender provide context for behavior analysis
3. Person Embeddings: Enable tracking individuals across multiple cameras
4. Pose/Clothing: Inform behavioral assessment (suspicious posture, face coverings)

The backend stores enrichment results in the detection record and passes the complete context to Nemotron for comprehensive risk scoring.

Environment Variables¶

YOLO26¶

Legacy standalone container only (ai/yolo26/model.py):

Nemotron¶

From the ai-llm service in docker-compose.prod.yml:

Enrichment¶

Legacy enrichment container only (ai/enrichment/model.py). The gateway ignores these; its model paths and devices come from models.yml (ai/gateway/entrypoint.sh exports the device variables, ai/gateway/patch_triton_configs.py rewrites Triton instance groups at startup).

Adding New Models¶

The steps below are for the legacy enrichment container (ai/enrichment/). To add a model to the production gateway instead, add an entry to models.yml (its triton_name must match a model directory under ai/triton/model_repository/ and an entry in ALL_MODELS in ai/gateway/main.py), export it to ONNX if applicable (ai/gateway/export/), and wire a router call in the matching adapter under ai/gateway/adapters/. models.yml is the single source of truth for GPU/CPU placement — ai/gateway/patch_triton_configs.py rewrites the Triton config.pbtxt files from it at boot.

Step 1: Create Model Wrapper¶

Create a new file in ai/enrichment/models/:

# ai/enrichment/models/new_model.py
from typing import Any
import torch
from PIL import Image


class NewModelClassifier:
    def __init__(self, model_path: str, device: str = "cuda:0"):
        self.model_path = model_path
        self.device = device
        self.model = None
        self.processor = None

    def load_model(self) -> None:
        """Load model and processor."""
        from transformers import AutoModelForXxx, AutoProcessor

        self.processor = AutoProcessor.from_pretrained(self.model_path)
        self.model = AutoModelForXxx.from_pretrained(self.model_path)
        if "cuda" in self.device and torch.cuda.is_available():
            self.model = self.model.to(self.device)
        self.model.eval()

    def predict(self, image: Image.Image) -> dict:
        """Run inference."""
        inputs = self.processor(images=image, return_tensors="pt")
        if "cuda" in self.device:
            inputs = {k: v.to(self.device) for k, v in inputs.items()}
        with torch.no_grad():
            outputs = self.model(**inputs)
        return self._postprocess(outputs)

    def _postprocess(self, outputs) -> dict:
        """Convert model outputs to API response."""
        return {"result": "..."}

Step 2: Add to Model Registry¶

Update ai/enrichment/model_registry.py:

def create_model_registry(device: str = "cuda:0") -> dict[str, ModelConfig]:
    registry = {}

    # ... existing models ...

    # New Model (~XGB)
    new_model_path = os.environ.get("NEW_MODEL_PATH", "/models/new-model")
    registry["new_model"] = ModelConfig(
        name="new_model",
        vram_mb=1000,  # Estimated VRAM usage
        priority=ModelPriority.MEDIUM,  # Choose appropriate priority
        loader_fn=lambda: _create_and_load_model(NewModelClassifier, new_model_path, device),
        unloader_fn=_unload_model,
    )

    return registry

Step 3: Update Detection Type Mapping¶

Add trigger conditions in model_registry.py:

def get_models_for_detection_type(detection_type: str, ...) -> list[str]:
    detection_model_mapping = {
        # ... existing mappings ...
        "new_type": ["new_model", "depth_estimator"],
    }

Step 4: Add API Endpoint (Optional)¶

Update ai/enrichment/model.py if direct endpoint access is needed:

@app.post("/new-classify")
async def new_classify(request: ImageRequest) -> NewClassifyResponse:
    model = await model_manager.get_model("new_model")
    result = model.predict(image)
    return NewClassifyResponse(**result)

Step 5: Update Docker Compose¶

For the legacy service, add the model volume mount in docker-compose.prod.yml:

ai-enrichment:
  volumes:
    - /export/ai_models/new-model:/models/new-model:ro

Step 6: Update Documentation¶

1. Add model details to this file (docs/ai/model-zoo.md)
2. Update ai/enrichment/AGENTS.md with endpoint documentation
3. Add the HuggingFace link where that service's AGENTS.md names the model (for gateway models, the HF repo goes in the hf_repo field of models.yml)

Hardware Requirements¶

The compose files size GPU placement around a two-GPU host: the LLM gets one GPU and Triton the other (the comments in docker-compose.prod.yml describe an RTX A5500 24GB for the LLM side and an NVIDIA A400 4GB class card for the light enrichment side; GPU_LLM/GPU_AI in .env pick the devices).

• GPU: NVIDIA with CUDA support, via the NVIDIA Container Toolkit
• Container Runtime: Podman (this project standard) or Docker

Related Documentation¶

• AI Pipeline AGENTS.md - Service overview
• AI Gateway AGENTS.md - Current production inference service
• Enrichment Service AGENTS.md - Detailed endpoint docs (legacy container)
• YOLO26 AGENTS.md - Detection service
• Florence-2 AGENTS.md - Vision-language service
• CLIP AGENTS.md - Embedding service
