Household Member Registration Workflow¶

This guide explains how to register household members and vehicles for face recognition and alert suppression.

Overview¶

Registering household members enables the system to:

• Recognize family members - Identify known people across all cameras
• Suppress false alerts - Avoid notifications for trusted individuals
• Track arrivals/departures - Optional notifications when members come and go
• Link vehicles - Associate vehicles with household members for plate recognition

Quick Start¶

Via the Web UI¶

1. Navigate to Settings > Household Settings
2. Click Add in the Members section
3. Enter member details:
4. Name (required)
5. Role (resident, family, service worker, frequent visitor)
6. Trust Level (full, partial, monitor)
7. Notes (optional)
8. Click Add to save

Via API¶

curl -X POST http://localhost:8000/api/household/members \
  -H "Content-Type: application/json" \
  -d '{
    "name": "John Smith",
    "role": "resident",
    "trusted_level": "full",
    "notes": "Primary resident"
  }'

Registration Workflow¶

Step 1: Create Household Member¶

Members represent people who should be recognized by the system.

Member Roles¶

Trust Levels¶

API Request¶

POST /api/household/members
Content-Type: application/json

{
  "name": "John Smith",
  "role": "resident",
  "trusted_level": "full",
  "typical_schedule": {
    "weekdays": "9:00-17:00",
    "weekends": "flexible"
  },
  "notes": "Works from home on Fridays"
}

API Response¶

{
  "id": 1,
  "name": "John Smith",
  "role": "resident",
  "trusted_level": "full",
  "typical_schedule": {
    "weekdays": "9:00-17:00",
    "weekends": "flexible"
  },
  "notes": "Works from home on Fridays",
  "created_at": "2026-01-28T10:00:00Z",
  "updated_at": "2026-01-28T10:00:00Z"
}

Step 2: Add Face Embeddings (Optional)¶

For face recognition to work, the system needs face embeddings for each member. Embeddings can be added from existing detection events.

From Events (Recommended)¶

When the system detects a person, you can link that detection to a household member:

POST /api/household/members/{member_id}/embeddings
Content-Type: application/json

{
  "event_id": 12345,
  "confidence": 0.95
}

Best Practices for Embeddings¶

Step 3: Register Vehicles (Optional)¶

Link vehicles to household members for license plate recognition.

API Request¶

POST /api/household/vehicles
Content-Type: application/json

{
  "description": "Silver Tesla Model 3",
  "vehicle_type": "car",
  "license_plate": "ABC123",
  "color": "Silver",
  "owner_id": 1,
  "trusted": true
}

Vehicle Types¶

UI Workflow¶

Accessing Household Settings¶

1. Click the Settings icon in the navigation
2. Select Household Settings from the sidebar
3. The page displays three sections:
4. Household Name - Editable household identifier
5. Members - List of registered members
6. Vehicles - List of registered vehicles

Adding a Member¶

1. Click the Add button in the Members section
2. Fill in the modal form:
3. Name (required) - Display name for the person
4. Role (required) - Select from dropdown
5. Trust Level (required) - Select alert behavior
6. Notes (optional) - Additional information
7. Click Add to create the member

Editing a Member¶

1. Find the member in the list
2. Click the Edit (pencil) icon
3. Modify fields in the modal
4. Click Update to save changes

Deleting a Member¶

1. Find the member in the list
2. Click the Delete (trash) icon
3. Confirm deletion in the dialog
4. Note: This also deletes associated embeddings

Managing Vehicles¶

The vehicle workflow is identical to members:

1. Click Add in the Vehicles section
2. Enter vehicle details
3. Optionally select an Owner from registered members
4. Mark as Trusted to suppress alerts

API Reference¶

Household Members¶

Registered Vehicles¶

Face Recognition (Advanced)¶

Data Model¶

HouseholdMember¶

interface HouseholdMember {
  id: number;
  name: string;
  role: 'resident' | 'family' | 'service_worker' | 'frequent_visitor';
  trusted_level: 'full' | 'partial' | 'monitor';
  typical_schedule?: Record<string, unknown> | null;
  notes?: string | null;
  created_at: string;
  updated_at: string;
}

RegisteredVehicle¶

interface RegisteredVehicle {
  id: number;
  description: string;
  vehicle_type: 'car' | 'truck' | 'motorcycle' | 'suv' | 'van' | 'other';
  license_plate?: string | null;
  color?: string | null;
  owner_id?: number | null;
  trusted: boolean;
  created_at: string;
}

Alert Behavior¶

Trust Level Effects¶

Schedule Configuration¶

The typical_schedule field accepts a JSON object defining expected presence times:

{
  "weekdays": "9:00-17:00",
  "weekends": "flexible",
  "monday": "8:00-18:00",
  "holidays": "not expected"
}

For partial trust members, detections outside scheduled times generate alerts.

Troubleshooting¶

Member Not Being Recognized¶

Possible Causes:

1. No embeddings added for the member
2. Insufficient embeddings (need 5+)
3. Poor quality source images
4. Significant appearance change

Solutions:

1. Add embeddings from recent, clear detections
2. Include multiple angles and lighting conditions
3. Use only high-confidence detections
4. Remove outdated embeddings, add current ones

Alerts Still Triggering for Known Members¶

Possible Causes:

1. Trust level set to monitor (logs only, no suppression)
2. Trust level set to partial with detection outside schedule
3. Face match confidence below threshold

Solutions:

1. Change trust level to full for complete suppression
2. Adjust typical schedule to include current time
3. Add more quality embeddings to improve matching

Vehicle Not Suppressing Alerts¶

Possible Causes:

1. License plate not entered or incorrect
2. trusted flag not set to true
3. Plate OCR reading issues

Solutions:

1. Verify license plate matches exactly
2. Ensure trusted: true in vehicle settings
3. Check if plate is readable in camera view

Cannot Delete Member¶

Error: "Member has associated data"

Solution: Delete associated embeddings first, then delete the member. Alternatively, the system will cascade delete embeddings when the member is deleted.

Integration with Face Recognition¶

The household member system integrates with the face recognition pipeline:

1. Detection - YOLO26 detects persons in camera feed
2. Face Extraction - YOLO11-face finds faces in person regions
3. Embedding - CLIP generates 768-dim facial embeddings
4. Matching - Embeddings compared against household members
5. Alert Decision - Trust level determines alert behavior

Household Matching Flow¶

The system uses multiple identification methods -- face recognition, person re-identification, and vehicle plate OCR -- to match detections against registered household members and vehicles. A successful match lowers the risk score based on the member's trust level.

flowchart TB
    D[Person Detection] --> FR[Face Recognition]
    D --> RE[Person Re-ID]
    D --> VP[Vehicle Plate OCR]
    FR --> M{Match Found?}
    RE --> M
    VP --> M
    M -->|Yes| HM[Household Member Identified]
    M -->|No| UK[Unknown Person/Vehicle]
    HM --> LOW[Lower Risk Score]
    UK --> NORM[Normal Risk Assessment]

For detailed face recognition documentation, see Face Recognition Guide.

Privacy Considerations¶

Data Stored¶

Data Deletion¶

When a member is deleted:

• All associated embeddings are cascade deleted
• Historical detection matches remain (anonymized)
• Vehicle ownership links are cleared

Local Processing¶

All face recognition runs locally:

• No cloud API calls
• No external data sharing
• Embeddings are numerical vectors, not images
